| MOEDL parameter project |
small round jar | JZC300 | JZC350 | JZC400 | JZM500 | JZM750 | JZM1000 | |
| work performance | output capacity | 350L | 300L | 350L | 400L | 500L | 750L | 1000L |
| Feed capacity | 400L | 350L | 500L | 550L | 700L | 1000L | 1200L | |
| productivity | 4-6m³/Time | 6-8m³/Time | 8-12m³/Time | 10-14m³/Time | 15-18m³/Time | 18-22m³/Time | 20-25m³/Time | |
| Mixing drum speed | 14r/min | 14r/min | 14r/min | 14r/min | 13r/min | 13r/min | 13r/min | |
| Maximum particle size of aggregate | 60mm | 60mm | 60mm | 60mm | 60mm | 60mm | 60mm | |
| Water supply accuracy | error≤2% | error≤2% | error≤2% | error≤2% | error≤2% | error≤2% | error≤2% | |
| electric motor | Stirring motor | 4KW | 4kw | 5.5kw | 7.5kw | 4kw*2 | 5.5kw*2 | 7.5kw*2 |
| lift motor | 4kw | 4.5kw | 4.5kw | 5.5kw | 7.5kw | 7.5kw | ||
| water pump motor | 0.55kw | 0.55kw | 0.55kw | 1.1kw | 1.1kw | 1.1kw | ||
| vibrator | * | * | 0.12KW | 0.12KW | 0.12KW | 0.12KW | ||
| Tire specifications | 6.5-16 | 6.5-16 | 6.5-16 | 6.5-16 | 6.5-16 | 6.5-16 | ||
| Max drag speed | 20km/h | 20km/h | 20km/h | 20km/h | 20km/h | 20km/h | ||
| Total Weight | 270KG | 1000KG | 1200KG | 1300KG | 2300KG | 2700KG | 3400KG | |
